ALLBAND+ GNSS ACTIVE PATCH ANTENNA, SCREW MOUNT

Active AllBand+ GNSS Embedded PPO Patch Antenna with Screw Mount and Cable

Full-band GNSS in just 85 g. This high-performance multi-band active antenna is designed for professional applications requiring ultra-precise positioning across L1, L2, L5, L6 and L-Band frequencies (1164–1300 MHz, 1525–1606 MHz) — with no weight penalty. Remarkably light for a true all-band patch, it is ideal wherever every gram counts. Combining exceptional signal sensitivity with rugged durability, this antenna is engineered for mission-critical deployments in drones, autonomous systems, geodetic surveying and high-accuracy navigation.

GNSS Frequency Bands

• GPS: L1/L2/L5
• GLONASS: G1/G2/G3
• GALILEO: E1/E5a/E5b/E6
• BDS: B1I/B1C/B2a/B2b/B3
• QZSS: L1/L2C/L5/L6
• IRNSS: L5


Electrical

• Frequency Range: 1164–1300 MHz, 1525–1606 MHz
• Impedance: 50 Ω
• Polarization: RHCP
• Radiation Pattern: Directional
• Axial Ratio: L1 - 1.36; B1 - 0.85; G1 - 2.23; L5/E5a - 1.53; E5b/B2b - 2.31; L2 - 2.56; G2 - 2.39; B3 - 2.28; E6 - 1.88

LNA Electrical

• LNA Gain: 38 ±4 dB
• Noise Figure: ≤ 2.5 dB
• Output VSWR: < 2.0
• Filter Out-of-Band Attenuation:
  ≥ 60 dB f0 & f1 ±100 MHz
  f0: (1164 MHz, 1300 MHz)
  f1: (1525 MHz, 1609 MHz)
• Working Voltage: 3–5 V
• Working Current: 19.6 ±4 mA


Mechanical

• Dimensions: 78.6 mm × 75.6 mm × 16.2 mm
• Material: PCB + PPO
• Cable length 89 ±5 mm
• Connector Type: IPEX (U.FL)
• Mounting Type: Screw
• Typical Weight: 85 g

Environmental

• Operating Temperature: -40 °C to +85 °C
• Storage Temperature: -40 °C to +85 °C
• RoHS, REACH, POPs Compliant
